Stainless Steel Wire Rope Mesh is engineered using high-quality SS316 stainless steel cables, connected with precision-made ferrules to create a flexible yet highly stressable structure. It is widely used for both two-dimensional and three-dimensional applications. The mesh retains its shape indefinitely, is weather-resistant, UV-stabilized, and requires minimal maintenance throughout its long lifespan
Its high corrosion resistance makes it the most durable option for harsh outdoor environments. Mesh openings can be customized from 25 mm to 300 mm, and rope diameters are available in the 1.00 mm – 3.00 mm range as per project requirements.
Vibrant Technik offers contemporary architectural materials.
Stainless steel rope mesh is versatile and suited for numerous architectural and safety applications, including:
Facades and Green Walls
Multi-Level Car Park Facades
Balustrades (as a low-maintenance alternative to glass)
Fall protection systems
Safety nets for under-construction sites
Vertical school buildings for child-fall protection
Enclosing emergency staircases in public buildings (metro stations, hospitals, etc.)
Lighting support for large commercial & residential façade installations
Security meshes for prisons
Separation meshes for multiple industrial and architectural requirements
Its adaptability makes it ideal for both functional and aesthetic purposes.
Ferrule type cable mesh exhibits physical properties similar to knotted mesh but features a unique combination of seamless ferrules that join cables into a durable metal fabric. It adapts beautifully to challenging 3D tensile structures.
Key Advantages:
High Transparency
The rhombus-shaped mesh design allows maximum airflow and light. With a subtle silver finish, it blends effortlessly with surroundings ideal for aviaries, animal enclosures, ceilings, and parking structures.
High Strength
SS316 material combined with seamless ferrules ensures excellent load-bearing capability and long-term dependability.
High Flexibility & Impact Resistance
The flexible structure absorbs impact effectively, making it ideal for balustrades on bridges, walkways, and staircases. Its flexibility also allows creative freedom in architectural design.
Non-Flammable
Being non-flammable and environmentally friendly, it is suitable for fire escape and emergency exit enclosures.
Anti-Climb Safety
Small rhombus apertures prevent footholds, making the mesh perfect for schools, museums, stadiums, and children’s activity zones.
Weather & Corrosion Resistance
With SS316 construction, the mesh withstands harsh Indian weather and UV exposure without any need for additional coatings.
Easy Installation & Maintenance-Free
It can be mounted to steel frames easily using basic hardware. Once installed, it retains shape and tension without requiring periodic adjustments.
Additionally, this mesh offers high recyclability, a lightweight profile, and a lifespan exceeding 30+ years.
Rope Thickness:
1.0 mm, 1.5 mm, 2.0 mm, 2.5 mm, 3.0 mm
Mesh Opening Size:
25 mm – 300 mm (measured with one rhombus angle stretched to 60°)Cable Material:
Stainless Steel SS316Ferrule Material Options:
Tinned copper, nickel-plated copper, stainless steel, or aluminumCable Construction:
7 × 7 (for 1.5 mm, 2 mm, 2.5 mm cables)
7 × 19 (for 3 mm, 4 mm cables)
These specifications can be customized as per project requirements.
Vibrant Technik offers premium-grade stainless steel rope mesh that stands out due to:
Exceptional strength and durability
High flexibility and impact resistance
Excellent corrosion resistance
Ability to withstand extreme outdoor conditions in India
Customizable sizes, diameters, and designs
Virtually zero maintenance
Long service life (30+ years)
Suitable for both architectural aesthetics and safety applications
Stainless Steel Wire Rope Mesh, made from robust SS316 cables, is an advanced, flexible, and resilient solution for modern architectural and safety needs. Its ability to adapt to a wide range of applications—such as car park facades, fall protection systems, green facades, balustrades, lighting support, and security enclosures—makes it a preferred choice for contemporary design and infrastructure projects.
Vibrant Technik’s stainless steel and rope mesh systems offer superior strength, flexibility, impact resistance, and unmatched corrosion protection. With minimal maintenance and exceptional longevity, these meshes ensure both safety and modern aesthetics for any installation.
